UIYCI2538A

by Coaxial-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Coaxial Isolator for global customers. UIYCI2538A is a Coaxial Isolator in Frequency Range of 700~5000 MHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 30%, Insertion Loss Max is 0.30~0.50 dB and Isolation Min is 18.0~23.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of 100/150/200 W.

Product Specifications

Product Details

  • Part Number
    UIYCI2538A
  • Description
    700 to 2500 MHz Coaxial Isolator

General Parameters

  • Frequency Range
    700~5000 MHz
  • Bandwidth Max
    30%
  • Insertion Loss Max
    0.30~0.50 dB
  • Isolation Min
    18.0~23.0 dB
  • Forward Power
    100/150/200 W
  • Reverse Power
    30 W
  • VSWR Max
    1.20~1.30
  • Impedance
    50 Ω
  • Connector Type
    N-F/SMA-F
  • Size
    25.4*38.5*15 mm
  • Weight
    /
  • Operating Temperature
    -40~+85 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes

Technical Documents

Specifications

Part Number Frequency Range (MHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR Max Forward Power (W) Reverse Power (W) Choose
UIYCI2538A700T750SF 700-750 0.40 20.0 1.25 100 100
UIYCI2538A869T894NF 869-894 0.30 23.0 1.20 200 100
UIYCI2538A925T960SF 925-960 0.30 23.0 1.20 100 100
UIYCI2538A1200T1400SF 1200-1400 0.30 23.0 1.20 150 100
UIYCI2538A1500T1700NF 1500-1700 0.30 23.0 1.20 200 100
UIYCI2538A1700T2200SF 1700-2200 0.50 18.0 1.30 100 100
UIYCI2538A1700T1900NFTNM 1700-1900 0.35 21.0 1.25 200 100
UIYCI2538A1900T2200NFTNM 1900-2200 0.35 21.0 1.25 200 100
UIYCI2538A2000T2500SF 2000-2500 0.50 20.0 1.25 100 100
UIYCI2538A2000T2700SF 2000-2700 0.50 18.0 1.30 100 100
UIYCI2538A2300T2500SF 2300-2500 0.30 23.0 1.20 100 100
UIYCI2538A2300T3000SF 2300-3000 0.50 18.0 1.30 100 100
UIYCI2538A2400T2600SF 2400-2600 0.30 23.0 1.20 100 100
UIYCI2538A2500T2700NF 2500-2700 0.30 23.0 1.20 200 100
UIYCI2538A2600T3300SF 2600-3300 0.50 18.0 1.30 100 100
UIYCI2538A2700T3100SF 2700-3100 0.40 20.0 1.25 100 100
UIYCI2538A2850T3300SF 2850-3300 0.40 20.0 1.25 100 100
UIYCI2538A3000T3600SF 3000-3600 0.40 20.0 1.25 100 100
UIYCI2538A3500T4000SF 3500-4000 0.40 20.0 1.25 100 100
UIYCI2538A4000T4600SF 4000-4600 0.40 20.0 1.25 100 100
UIYCI2538A4400T5000SF 4400-5000 0.40 20.0 1.25 100 100
