UIYBCI1025A

by Coaxial-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Coaxial Isolator for global customers. UIYBCI1025A is a Coaxial Isolator in Frequency Range of 18.0~28.0 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 100%, Insertion Loss Max is 0.70~0.90 dB and Isolation Min is 20.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of 10 W.

Product Specifications

Product Details

  • Part Number
    UIYBCI1025A
  • Description
    18.0 to 28.0 GHz Coaxial Isolator

General Parameters

  • Frequency Range
    18.0~28.0 GHz
  • Bandwidth Max
    100%
  • Insertion Loss Max
    0.70~0.90 dB
  • Isolation Min
    20.0 dB
  • Forward Power
    10 W
  • Reverse Power
    2 W
  • VSWR Max
    1.30
  • Impedance
    50 Ω
  • Connector Type
    2.92-F
  • Size
    10.2*25.6*12.5 mm
  • Weight
    /
  • Operating Temperature
    -55~+85 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes

Technical Documents

Specifications

Part Number Frequency Range (GHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR Max Forward Power (W) Reverse Power (W) Choose
UIYBCI1025A18T265KF 18.0 ~ 26.5 0.70 20.0 1.30 10 2
UIYBCI1025A23T28KF 23.0 ~ 28.0 0.90 20.0 1.30 10 2
