MG0505-08

by Microstrip-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Microstrip Isolator for global customers. MG0505-08 is a Microstrip Isolator in Frequency Range of 17.7~23.55 GHz. It is made of high quality materials under a high standard, the Insertion Loss Max of this product is 0.90 dB, Isolation Min is 15.0 dB and VSWR Max is 1.50. The component has a good working performance and stability, it is ideal for handling a Forward Power of 2 W.

Product Specifications

Product Details

  • Part Number
    MG0505-08
  • Description
    17.7 to 23.55 GHz Microstrip Isolator

General Parameters

  • Frequency Range
    17.7~23.55 GHz
  • Insertion Loss Max
    0.90 dB
  • Isolation Min
    15.0 dB
  • VSWR Max
    1.50
  • Forward Power
    2 W
  • Reverse Power
    1 W
  • Impedance
    50 Ω
  • Connector Type
    Micro strip
  • Size
    5.0*5.0*3.5 mm
  • Weight
    /
  • Operating Temperature
    -55~+85 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes

Technical Documents

Specifications

Part Number Frequency Range (GHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR Max Forward Power (W) Reverse Power (W) Choose
MG0505-08-X/17.7-23.55GHz 17.7-23.55 0.90 15.0 1.50 2 1
