WHH6434A

by Dual-Junction-Circulator
RFHB04G18GPI Image

RF Solution offer a wide selection of Dual Junction Circulator for global customers. WHH6434A is a Dual Junction Circulator in Frequency Range of 2.0~4.0 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 100%, Insertion Loss Max is 1.00~1.20 dB and Isolation Min is 36.0~38.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of 100 W.

Product Specifications

Product Details

  • Part Number
    WHH6434A
  • Description
    2.0 to 4.0 GHz Dual Junction Circulator

General Parameters

  • Frequency Range
    2.0~4.0 GHz
  • Bandwidth Max
    100%
  • Insertion Loss Max
    1.00~1.20 dB
  • Isolation Min
    36.0~38.0 dB
  • Forward Power
    100 W
  • VSWR Max
    1.25~1.30
  • Impedance
    50 Ω
  • Connector Type
    Strip line
  • Size
    64.0*34.0*21.0 mm
  • Weight
    /
  • Operating Temperature
    -10~+60 ℃
  • Storage Temperature
    -30~+70 ℃
  • ROHS Compliant
    Yes


Technical Documents

Specifications

Part Number Frequency Range (GHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR （Max） Forward Power (W) Choose
WHH6434A-X/2.0-2.6GHz 2.0-2.6 1.0 36 1.30 100
WHH6434A-X/2.0-2.9GHz 2.0-2.9 1.0 36 1.30 100
WHH6434A-X/2.0-3.0GHz 2.0-3.0 1.0 36 1.30 100
WHH6434A-X/2.0-3.5GHz 2.0-3.5 1.2 36 1.30 100
WHH6434A-X/2.0-4.0GHz 2.0-4.0 1.2 36 1.30 100
WHH6434A-X/2.35-4.0GHz 2.35-4.0 1.0 36 1.30 100
WHH6434A-X/2.4-4.0GHz 2.4-4.0 1.2 36 1.30 100
WHH6434A-X/2.5-3.8GHz 2.5-3.8 1.0 36 1.35 100
WHH6434A-X/2.5-3.5GHz 2.5-3.5 1.2 38 1.25 100
WHH6434A-X/2.5-4.0GHz 2.5-4.0 1.2 36 1.30 100
