Broadband Isolator RFTYT

by Broadband-Isolator
RFHB04G18GPI Image

Broadband Isolator From RFTYT, High Power, for use in RF & Microwave wireless applications, cover frequency range from 0.8 GHz to 18.0 GHz, cover frequency band which are FM, VHF, UHF, GSM, CDMA, WCDMA, Wimax, LTE, L, S, C, X, Ku, K band.

Product Specifications

Product Details

  • Part Number
    Broadband Isolator RFTYT
  • Description
    0.8 to 18.0 GHz Broadband Isolator

General Parameters

  • Frequency Range
    0.8-18.0 GHz
  • Impedance
    50 Ω
  • ROHS Compliant
    Yes
  • Reverse Power
    10-100 W
  • Forward Power
    30-150 W

Frequency range 56MHz to 40GHz, BW up to 13.5GHz.

Military, space and commercial applications.

Low insertion loss, high isolation, high power handling.

Custom design available upon request.

Technical Documents

Specifications

Part Number Frequency Range (GHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR Max Forward Power (W) Reverse Power (W) Connector Type Operating Temperature (℃) Storage Temperature (℃) Dimension WxLxH (mm) Choose
TG5656AS 0.8-2.0 1.20 13.0 1.60 50 20 SMA-K 25~+60 0~+80 56.0*56.0*20.0
TG6466KN 1.0-2.0 0.70-0.80 16.0-17.0 1.40 150 100 N-K -10~+60 -50~+90 64.0*66.0*26.0
TG6466KS 1.0-2.0 0.70-0.80 16.0-17.0 1.40 150 100 SMA-K -10~+60 -50~+90 64.0*66.0*26.0
TG5050AN 1.35-2.7 0.60 17.0 1.35 150 20 N-K -10~+60 -50~+90 50.8*49.5*19.0
TG5050AS 1.35-2.7 0.60 17.0 1.35 150 20 SMA-K -10~+60 -50~+90 50.8*49.5*19.0
TG4040AN 1.5-3.0 0.70 17.0 1.35 100 20/100 N-K -10~+60 -50~+90 40.0*40.0*20.0
TG4040AS 1.5-3.0 0.70 17.0 1.35 100 20/100 SMA-K -10~+60 -50~+90 49.5*50.8*19.0
TG3234AN 2.0-4.0 0.50 18.0 1.30 150 20/100 N-K -10~+60 -50~+90 32.0*34.0*21.0
TG3234AS 2.0-4.0 0.50 18.0 1.30 150 20/100 SMA-K -10~+60 -50~+90 32.0*34.0*21.0
TG3234BN 2.0-4.0 0.60 18.0 1.30 150 20/100 N-K -10~+60 -50~+90 32.0*34.0*21.0
TG3234BS 2.0-4.0 0.50 18.0 1.30 150 20/100 SMA-K -10~+60 -50~+90 32.0*34.0*21.0
TG3030BS 2.0-6.0 0.85-1.70 12.0 1.50-1.60 50 20 SMA-K -40~+70 -50~+90 30.5*30.5*15.0
TG6237AS 2.0-8.0 1.20-1.70 13.0-1.50 1.50-1.60 20 10 SMA-K -10~+60 -50~+90 62.0*36.8*19.6
TG2528CN 3.0-6.0 0.45-0.50 18.0-20.0 1.25-1.30 150 20/100 N-K -10~+60 -50~+90 A Type：25.4*28.0*14.0/B Type：25.4*28.0*15.0
TG2528CS 3.0-6.0 0.45-0.50 18.0-20.0 1.25-1.30 150 20/100 SMA-K -10~+60 -50~+90 A Type：25.4*28.0*14.0/B Type：25.4*28.0*15.0
TG2123BS 4.0-8.0 0.60 18.0 1.30 100 20 SMA-K -10~+60 -30~+70 21.0*22.5*15.0
TG1622BS 6.0-18.0 0.80-1.50 9.5-17.0 1.40-2.00 30 10 SMA-K 0~+60 -50~+90 16.0*26.6*14.0
TG1319CS 8.0-12.0 0.50-0.60 16.0-18.0 1.30-1.40 30 10 SMA-K -10~+60 -50~+90 13.0*19.0*12.7
WG6466K 0.95-2.0 0.70-0.80 16.0-17.0 1.40 150 100 Microstrip line -10~+60 -40~+90 64.0*66.0*26.0
WG5050A 1.5-3.0 0.60 17.0 1.35 150 20/100 Microstrip line -10~+60 -50~+90 50.8*49.5*19.0
WG4040A 1.7-2.7 0.70 17.0 1.35 100 20/100 Microstrip line -10~+60 -50~+90 40.0*40.0*20.0
WG3234A 2.0-4.0 0.50 18.0 1.30 150 20/100 Microstrip line -10~+60 -50~+90 32.0*34.0*21.0
WG3234B 2.0-4.0 0.50 18.0 1.30 150 20/100 Microstrip line -10~+60 -50~+90 32.0*34.0*21.0
WG3030B 2.0-6.0 0.85-1.70 12.0 1.50-1.60 50 20 Microstrip line -10~+60 -40~+70 30.5*30.5*15.0
WG2528C 3.0-6.0 0.45-0.50 18.0-20.0 1.25-1.30 150 20/100 Microstrip line -10~+60 -50~+90 25.4*28.0*14.0
WG1623X 3.8-8.0 0.70-0.90 14.0-16.0 1.50-1.70 100 100 Microstrip line -40~+80 -50~+90 16.0*23.0*6.4
WG2123B 4.0-8.0 0.60 18.0 1.30 100 20 Microstrip line -10~+60 -50~+90 21.0*22.5*15.0
WG1622B 6.0-18.0 0.80-1.50 9.50-17.0 1.40-2.00 30 10 Microstrip line -10~+60 -50~+90 16.0*21.5*14.0
WG1319C 8.0-12.0 0.50-0.60 16.0-18.0 1.30-1.40 30 10 Microstrip line -10~+60 -50~+90 13.0*19.0*12.7
