Dual Junction Isolator

There are 29 related products in the Dual Junction Isolator category
  • Parametric Search
  • Download Datasheets
  • Get Quotations
  • Description: 8.0 to 12.0 GHz Dual Junction Isolator
  • Frequency Range: 8.0~12.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.80~1.00 dB
  • Isolation Min: 20.0~40.0 dB
  • Forward Power: 30 W
  • Reverse Power: 10 W
  • Description: 4.0 to 8.0 GHz Dual Junction Isolator
  • Frequency Range: 4.0~8.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.80~1.20 dB
  • Isolation Min: 36.0~38.0 dB
  • Forward Power: 50 W
  • Reverse Power: 10 W
  • Description: 3.0 to 6.0 GHz Dual Junction Isolator
  • Frequency Range: 3.0~6.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.60~1.60 dB
  • Isolation Min: 36.0~38.0 dB
  • Forward Power: 100 W
  • Reverse Power: 100 W
  • Description: 2.0 to 4.0 GHz Dual Junction Isolator
  • Frequency Range: 2.0~4.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 1.00~1.20 dB
  • Isolation Min: 36.0~38.0 dB
  • Forward Power: 100 W
  • Reverse Power: 20 W
  • Description: 700 to 4000 MHz Dual Junction Isolator
  • Frequency Range: 700~4000 MHz
  • Bandwidth Max: 5~20%
  • Insertion Loss Max: 0.60~1.00 dB
  • Isolation Min: 36.0~46.0 dB
  • Forward Power: 100 W
  • Reverse Power: 100 W
  • Description: 700 to 2700 MHz Dual Junction Isolator
  • Frequency Range: 700~2700 MHz
  • Bandwidth Max: 5~20%
  • Insertion Loss Max: 0.60~1.20 dB
  • Isolation Min: 36.0~46.0 dB
  • Forward Power: 100 W
  • Reverse Power: 20 W
  • Description: 400 to 1850 MHz Dual Junction Isolator
  • Frequency Range: 400~1850 MHz
  • Bandwidth Max: 5~20%
  • Insertion Loss Max: 0.40~1.40 dB
  • Isolation Min: 32.0~50.0 dB
  • Forward Power: 100 W
  • Reverse Power: 20 W
  • Description: 350 to 4300 MHz Dual Junction Isolator
  • Frequency Range: 350~4300 MHz
  • Bandwidth Max: 5~15%
  • Insertion Loss Max: 0.40~1.40 dB
  • Isolation Min: 34.0~50.0 dB
  • Forward Power: 200 W
  • Reverse Power: 20 W
  • Description: 300 to 1250 MHz Dual Junction Isolator
  • Frequency Range: 300~1250 MHz
  • Bandwidth Max: 5~20%
  • Insertion Loss Max: 0.60~1.60 dB
  • Isolation Min: 30.0~50.0 dB
  • Forward Power: 100 W
  • Reverse Power: 20 W
  • Description: 300 to 1250 MHz Dual Junction Isolator
  • Frequency Range: 300~1250 MHz
  • Bandwidth Max: 5~20%
  • Insertion Loss Max: 0.60~1.60 dB
  • Isolation Min: 32.0~50.0 dB
  • Forward Power: 100 W
  • Reverse Power: 20 W
  • Description: 80 to 230 MHz Dual Junction Isolator
  • Frequency Range: 80~230 MHz
  • Bandwidth Max: 5~30%
  • Insertion Loss Max: 0.80~2.20 dB
  • Isolation Min: 36.0~46.0 dB
  • Forward Power: 50/100 W
  • Reverse Power: 20/100 W
  • Description: 8.0 to 12.0 GHz Dual Junction Isolator
  • Frequency Range: 8.0~12.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.60~1.20 dB
  • Isolation Min: 32.0~50.0 dB
  • Forward Power: 30 W
  • Reverse Power: 10 W
