Low Pass Filter

There are 19 related products in the Low Pass Filter category
  • Parametric Search
  • Download Datasheets
  • Get Quotations
  • Description: DC~8000 MHz Low Pass Filter
  • Frequency Range: DC~8000 MHz
  • Insertion Loss Max: 0.35 dB
  • Rejection Min: 25dB@9600MHz / 55dB@15000MHz
  • VSWR Max: 1.50
  • Rated Power: 50 W
  • Impedance: 50 Ω
  • Description: DC~6000 MHz Low Pass Filter
  • Frequency Range: DC~6000 MHz
  • Insertion Loss Max: 2.0 dB
  • Rejection Min: 70dB@9000-18000MHz
  • VSWR Max: 2.00
  • Rated Power: 20 W
  • Impedance: 50 Ω
  • Description: DC~5800 MHz Low Pass Filter
  • Frequency Range: DC~5800 MHz
  • Insertion Loss Max: 2.0 dB
  • Rejection Min: 40dB@6148-18000MHz
  • VSWR Max: 2.00
  • Rated Power: 20 W
  • Impedance: 50 Ω
  • Description: DC~5150 MHz Low Pass Filter
  • Frequency Range: DC~5150 MHz
  • Insertion Loss Max: 2.0 dB
  • Rejection Min: 50dB@6000-16000MHz
  • VSWR Max: 2.00
  • Rated Power: 15 W
  • Impedance: 50 Ω
  • Description: DC~4500 MHz Low Pass Filter
  • Frequency Range: DC~4500 MHz
  • Insertion Loss Max: 2.0 dB
  • Rejection Min: 40dB@4452-21000MHz
  • VSWR Max: 2.00
  • Rated Power: 20 W
  • Impedance: 50 Ω
  • Description: DC~4200 MHz Low Pass Filter
  • Frequency Range: DC~4200 MHz
  • Insertion Loss Max: 2.0 dB
  • Rejection Min: 40dB@4452-21000MHz
  • VSWR Max: 2.00
  • Rated Power: 20 W
  • Impedance: 50 Ω
  • Description: DC~2970 MHz Low Pass Filter
  • Frequency Range: DC~2970 MHz
  • Insertion Loss Max: 1.0 dB
  • Rejection Min: 50dB@3960-9900MHz
  • VSWR Max: 1.50
  • Rated Power: 40 W
  • Impedance: 50 Ω
  • Description: DC~2700 MHz Low Pass Filter
  • Frequency Range: DC~2700 MHz
  • Insertion Loss Max: 1.5 dB
  • Rejection Min: 50dB@4000-8000MHz
  • VSWR Max: 1.50
  • Rated Power: 10 W
  • Impedance: 50 Ω
  • Description: DC~2200 MHz Low Pass Filter
  • Frequency Range: DC~2200 MHz
  • Insertion Loss Max: 1.5 dB
  • Rejection Min: 10dB@2400MHz / 60dB@2650-7000MHz
  • VSWR Max: 1.50
  • Rated Power: 10 W
  • Impedance: 50 Ω
  • Description: DC~2000 MHz Low Pass Filter
  • Frequency Range: DC~2000 MHz
  • Insertion Loss Max: 1.0 dB
  • Rejection Min: 50dB@2600-6000MHz
  • VSWR Max: 1.50
  • Rated Power: 40 W
  • Impedance: 50 Ω
  • Description: DC~1600 MHz Low Pass Filter
  • Frequency Range: DC~1600 MHz
  • Insertion Loss Max: 2.0 dB
  • Rejection Min: 40dB@1696-11000MHz
  • VSWR Max: 2.00
  • Rated Power: 20 W
  • Impedance: 50 Ω
  • Description: DC~1400 MHz Low Pass Filter
  • Frequency Range: DC~1400 MHz
  • Insertion Loss Max: 2.0 dB
  • Rejection Min: 40dB@1484-11000MHz
  • VSWR Max: 2.00
  • Rated Power: 20 W
  • Impedance: 50 Ω
